1981 SOLFRUNT | 30-0-150 PSI (150021X)

The Solid Front Model 1981 and 1981 Advantage 4-1/2" process gauges feature 316L stainless steel wetted surfaces and a seamless Bourdon tube. The 1981 Advantage offers a dampened movement option for some benefits of liquid filling. Their PET turret style case provides superior impact strength and chemical resistance, ideal for chemical and petrochemical processing. Available dry, dampened, or liquid filled, with options for field filling using a liquid fill kit or EZ Fill design. Ranging from 30" Hg vacuum to 11600 psi, these SOLFRUNT gauges are versatile. Field liquid filling is simple with the low-connected PET turret case and EZ Fill version. Pointer adjustments are easy with micro-adjustable pointer screws accessible by removing the ring and window.

• SIZE: 4-1/2"
• ACCURACY: ACCURACY: ±0.5% of span (Grade 2A), except for Type 316L seamless stainless steel bourdon tubes in the 10000 to 11600 psi range, with ±0.5% accuracy on ascending pressure and ±1.0% on descending pressure.
• BOURDON TUBE: 316L seamless stainless steel/TIG welded
• WINDOW: High temp acrylic, optional laminated shatter-resistant safety glass (G038312)
• MOVEMENT: Geared with corrosion-resistant 300 series stainless steel components; optional dampened movement on Advantage unit
• DIAL: Aluminum with baked white background and black markings; optional luminescent or bright yellow dial
• POINTER: Anodized aluminum, micro-adjustable with black finish; optional red or lazy hand pointer (lazy hand for dry gauges only)
• CASE AND RING: PET turret case (black) with glass-filled polypropylene threaded ring and pressure-relieving back; EZ Fill option available
• CONNECTION: 316L stainless steel, 1/2-14 NPT standard (optional 1/4-18 NPT)
• LIQUID FILLING: Model 1981 available in liquid filled or field fillable (EZ Fill) configurations
• WEATHER PROTECTION: NEMA 4X/IP66 with EZ Fill Case

Refer to the specification sheet for more details

Specification Sheet
